OTR-UA-12

ALUMINUM RACKS
Transport 18" x 26" Trays, 12" x 20" Pans, and Oval Trays
OTR Series

OTR-UA-12 Spec Sheet

Economical and functional aluminum racks for transport, bussing and storage

Model may differ from the image(s) shown.
Model may be shown with Optional Accessories.
Please Consult Factory.

DESCRIPTION

These sturdy aluminum racks provide an economical solution for your transport and storage needs. Fabricated from high tensile extruded aluminum, the "OTR Rack Series" hold up to the demands in hotels, motels, restaurants, hospitals, bakeries . . . and rugged enough for even correctional facilities.

They're heavy-duty, yet light weight and easy to maneuver, even when fully loaded with roasting pans, steam table pans, sheet trays, or oval tray sheet pans. The extruded aluminum runners are double welded for extra strength.

The OTR-UA-12 pan rack is easy to clean and can be completely sanitized, washed, or steam cleaned while remaining rust resistant.

FWE...the "Choice of the Professionals."

FEATURES

Agency Approvals
NSF - NSF International (formerly known as the National Sanitation Foundation) is an independent, non-profit organization that certifies food service equipment and ensures it is designed and constructed in a way that promotes food safety. FWE products that meet these standards bear the NSF mark.
You may also see a designation that a product meets NSF/ANSI, which adds rules from the American National Standards Institute to the testing. ANSI works closely with NSF to develop its food safety standards and complete testing to those.
Bumpers
No Bumper - No bumper
Caster
5" Casters - 5" Heavy-duty casters - polyurethane casters are long lasting and used for easy maneuverability, even when fully loaded
All Swivel Casters - All swivel casters allow for greater maneuverability. Great for tight turns or severe corners (such as on and off trucks or narrow hallways).
A drawback to the all swivel configuration is that it is harder to control the direction of the equipment when rolled in a straight line.
Mobile
Construction
Aluminum - Heavy duty extruded type 6063 aluminum alloy.
Door Count
No Doors
Door Hinge
No Doors
Door Latch
No Doors
Doors
No Doors - No doors - open storage
Handles
No Handles
Heat System
Non Heated - Non Heated
Hinging
No Doors
Slides and Shelves
Adjustable Universal Aluminum Slides

OPTIONS & ACCESSORIES

SHORT FORM SPEC

Specified unit shall be FWE Model No. OTR-UA-12, Aluminum Racks.

CONSTRUCTION. Heavy-duty extruded type 6063 aluminum alloy. All uprights and runners are fully welded.

CASTERS. 5" durable, non-marking, easy rolling, all swivel, polyurethane tire casters with 1.5" wheel shall be bolted to heavy-duty stress plate that is welded to the tubular frame.

TRAY GUIDES. OTR-UA tray guides are adjustable on 1.5" spacings. Spacings and ledge size vary in dimensions for intent of purpose and are indicated on the chart above.

LITERATURE

FWE products may be covered under one or more of the following U.S. patents: 288,299;238,300;3,952,609;4,192,991.
